2.5. Considerations for Configuring HA Services

You can create a cluster to suit your needs for high availability by configuring HA (high-availability) services. The key component for HA service management in the Red Hat High Availability Add-On, rgmanager, implements cold failover for off-the-shelf applications. In the Red Hat High Availability Add-On, an application is configured with other cluster resources to form an HA service that can fail over from one cluster node to another with no apparent interruption to cluster clients. HA-service failover can occur if a cluster node fails or if a cluster system administrator moves the service from one cluster node to another (for example, for a planned outage of a cluster node).
To create an HA service, you must configure it in the cluster configuration file. An HA service comprises cluster resources. Cluster resources are building blocks that you create and manage in the cluster configuration file — for example, an IP address, an application initialization script, or a Red Hat GFS2 shared partition.
An HA service can run on only one cluster node at a time to maintain data integrity. You can specify failover priority in a failover domain. Specifying failover priority consists of assigning a priority level to each node in a failover domain. The priority level determines the failover order — determining which node that an HA service should fail over to. If you do not specify failover priority, an HA service can fail over to any node in its failover domain. Also, you can specify if an HA service is restricted to run only on nodes of its associated failover domain. (When associated with an unrestricted failover domain, an HA service can start on any cluster node in the event no member of the failover domain is available.)
Figure 2.1, “Web Server Cluster Service Example” shows an example of an HA service that is a web server named "content-webserver". It is running in cluster node B and is in a failover domain that consists of nodes A, B, and D. In addition, the failover domain is configured with a failover priority to fail over to node D before node A and to restrict failover to nodes only in that failover domain. The HA service comprises these cluster resources:
  • IP address resource — IP address 10.10.10.201.
  • An application resource named "httpd-content" — a web server application init script /etc/init.d/httpd (specifying httpd).
  • A file system resource — Red Hat GFS2 named "gfs2-content-webserver".
Web Server Cluster Service Example
Web Server Cluster Service Example
Figure 2.1. Web Server Cluster Service Example

Clients access the HA service through the IP address 10.10.10.201, enabling interaction with the web server application, httpd-content. The httpd-content application uses the gfs2-content-webserver file system. If node B were to fail, the content-webserver HA service would fail over to node D. If node D were not available or also failed, the service would fail over to node A. Failover would occur with minimal service interruption to the cluster clients. For example, in an HTTP service, certain state information may be lost (like session data). The HA service would be accessible from another cluster node via the same IP address as it was before failover.

Note

For more information about HA services and failover domains, refer to Red Hat Cluster Suite Overview. For information about configuring failover domains, refer to Chapter 3, Configuring Red Hat High Availability Add-On With Conga(using Conga) or Chapter 5, Configuring Red Hat High Availability Add-On With Command Line Tools (using command line utilities).
An HA service is a group of cluster resources configured into a coherent entity that provides specialized services to clients. An HA service is represented as a resource tree in the cluster configuration file, /etc/cluster/cluster.conf (in each cluster node). In the cluster configuration file, each resource tree is an XML representation that specifies each resource, its attributes, and its relationship among other resources in the resource tree (parent, child, and sibling relationships).

Note

Because an HA service consists of resources organized into a hierarchical tree, a service is sometimes referred to as a resource tree or resource group. Both phrases are synonymous with HA service.
At the root of each resource tree is a special type of resource — a service resource. Other types of resources comprise the rest of a service, determining its characteristics. Configuring an HA service consists of creating a service resource, creating subordinate cluster resources, and organizing them into a coherent entity that conforms to hierarchical restrictions of the service.
The High Availability Add-On supports the following HA services:
  • Apache
  • Application (Script)
  • LVM (HA LVM)
  • MySQL
  • NFS
  • Open LDAP
  • Oracle
  • PostgreSQL 8
  • Samba
  • SAP
  • Tomcat 6
There are two major considerations to take into account when configuring an HA service:
  • The types of resources needed to create a service
  • Parent, child, and sibling relationships among resources
The types of resources and the hierarchy of resources depend on the type of service you are configuring.
The types of cluster resources are listed in Appendix B, HA Resource Parameters. Information about parent, child, and sibling relationships among resources is described in Appendix C, HA Resource Behavior.
